welcome to HISEA
Full Band Drone Jamming and Navigation Spoofing transmits high-power interference signals in a directional way which can accurately and quickly counter multi-target UAVs. The equipment can send out 4 channels of jamming signals simultaneously and the this signal could be any frequency within 300MHz～6GHz range. At the same time, this equipment can send out navigation spoofing signal to remotely spoofing drone.
Product Introduction
Full Band Drone Jamming and Navigation Spoofing transmits high-power interference signals in a directional way which can accurately and quickly counter multi-target UAVs. The equipment can send out 4 channels of jamming signals simultaneously and the this signal could be any frequency within 300MHz～6GHz range. At the same time, this equipment can send out navigation spoofing signal to remotely spoofing drone.
Products Features
(1)Link to full band detection equipment, support any countering signal within 300MHz～6GHz
(2)Simultaneously send 4 countering signals
(3)Link equipment to radar in order to spoof UAVs to target field
(4)High jamming-communication distance ratio: 10:1
(5)Valid long distance countering, distance＞10km
Performance Parameter
(1)The jam frequency band covers: 300MHz~6000MHz
(2)Output power:
• 400~1100MHz: ≥100W
• 1100~2700MHz: ≥100W
• 2700~6000MHz: ≥50W
(3) L1, GLONASS L1, BD2 B1: ≥50W
(4)Jam signal sideband suppression: 60dB
(5)The axis of equipment antenna surface is 0°~360° and pitch-5°~90°
(6)Platform speed: horizontal 20°/s, pitch 10°/s
(7)Signal jamming distance: ＞10km
(8)Navigation spoofing signal frequency includes BDS-2 B1, L1, GLONASS L1
(9)Single-channel instant jamming bandwidth: ≥200MHz
(10)UAV jamming-communication distance ratio ＞10：1 (i.e. DJI Mavic 2)
(11)UAV navigation receiver spoofing distance: ＞30km
(12)Number of simultaneous jamming bands: ≥4
(13)Power consumption: ≤1500W
(14)Weight: ≤70 kg
(15)Working temperature: -40°C + 65℃
(16)Storage conditions: -45°C + 70℃
